SFP-FE-SX-MM1310 Overview
Huawei SFP-FE-SX-MM1310 is Optical Transceiver.
It’s a Multi-mode Module.
SFP-FE-SX-MM1310 Specification
SFP-FE-SX-MM1310 Specification | |
Transceiver form factor | SFP |
Transmission speed | Fast Ethernet |
Center wavelength (nm) | 1310 |
Standard compliance | 1000BASE-FX |
Connector type | LC |
Applicable cable and maximum transmission distance | Multimode fiber (50 μm or 62.5 μm diameter) : 2 km |
Transmit power (dBm) | -9 to -14.0 |
Maximum receiver sensitivity (dBm) | -30.0 |
Overload power (dBm) | -14.0 |
Extinction ratio (dB) | 10 |
Operating temperature | 0°C to +70°C (32°F to +158°F) |
Net Dimension(D x W x H mm) | 145*80*35 |
Table 2 shows the Huawei hot switches which support SFP-FE-SX-MM1310.
Model | Description |
S2700-26TP-EI-DC | 24 x Ethernet 10 /100 ports , 2 dual-purpose 10 /100/1000 or SFP , DC -48V |
S2700-52P-EI-AC | 48 x Ethernet 10/100 ports, 4 Gig SFP, AC 110/220V |
S2700-26TP-EI-AC | 4 x Ethernet 10/100 ports, 2 dual-purpose 10/100/1000 or SFP, AC 110/220V |
S2700-9TP-PWR-EI | 8 x Ethernet 10/100 ports, PoE+, 1 dual-purpose 10/100/1000 or SFP, AC 110/220V |
S2700-26TP-PWR-EI | 24 x Ethernet 10/100 ports, 2 dual-purpose 10/100/1000 or SFP, PoE+, without power module |
S2700-9TP-EI-AC | 8 x Ethernet 10/100 ports,1 dual-purpose 10/100/1000 or SFP, AC 110/220V |
S3700-28TP-EI-AC | 24 x Ethernet 10/100 ports, 2 Gig SFP and 2 dual-purpose 10/100/1000 or SFP, AC 110/220V |
S3700-28TP-SI-AC | 24 x Ethernet 10/100 ports, 2 Gig SFP and 2 dual-purpose 10/100/1000 or SFP, AC 110/220V |
S3700-28TP-PWR-SI | 24 x Ethernet 10/100 PoE+ ports,2 Gig SFP and 2 dual-purpose 10/100/1000 or SFP,with 500W AC power supply |
