SFP-10G-USR

Transceiver   form factor

SFP+

Transmission   speed

10 Gbit/s

Center   wavelength (nm)

850

Standard   compliance

10Gbase-USR

Connector type

LC

Applicable   cable  and  maximum

transmission  distance

Multimode   fiber   (OM3) :  0.1 km

Transmit power   (dBm)

-7.3 to -1.0

Maximum   receiver  sensitivity  (dBm)

-10.7

Overload power   (dBm)

0.5

Extinction   ratio (dB)

3.0

Operating   temperature

0°C to 70°C (32°F to 158°F)

Net   Dimension(D x W x H mm)

145 x 80 x 35

S5700-28P-LI-AC

24 x Ethernet 10/100/1000 ports, 4 Gig SFP,

AC 110/220V

S5700-28TP-LI-AC

24 x Ethernet 10/100/1000ports,2 Gig SFP and

2 dual-purpose   10/100/1000 or SFP,AC 110/220V

S5700S-52P-LI-AC

48 x Ethernet 10/100/1000 ports, 4 Gig SFP,

AC 110/220V

S5700-28P-PWR-LI-AC

24 x Ethernet 10/100/1000 PoE+ ports, 4 Gig SFP,

AC 110/220V

S5700-10P-PWR-LI-AC

8 x Ethernet 10/100/1000 PoE+ ports, 2 Gig SFP,

AC 110/220V

S5720-36C-EI-AC

28 x Ethernet 10/100/1000 ports,4 of which are

dual-purpose  10/100/1000 or SFP,4 10 Gig SFP+,

1 interface slot, with 150W AC

S5700-28C-EI-AC

24 x Ethernet 10/100/1000 ports, with 1 interfaceslot,

with   150W AC power supply

S5720-56C-HI-AC

48 x Ethernet 10/100/1000 ports, 4 10 Gig SFP+,

with 2   interface slots, with 600W AC power supply

S5720-56PC-EI-AC

48 x Ethernet 10/100/1000 ports,4 Gig SFP,

with 1 interface   slot, with 150W AC power supply

S5720-56C-PWR-HI-AC

48 x Ethernet 10/100/1000 POE+ ports,4 10 Gig SFP+,

with 2   interface slots, with 1150W AC power supply
