SFP-10G-iLR Overview
Optical Transceiver,SFP+,9.8G,Single-mode Module 1310nm,1.4km,LC.
SFP-10G-iLR Specification | |
Transceiver form factor | SFP+ |
Transmission speed | 10 Gbit/s |
Center wavelength (nm) | 1310 |
Standard compliance | 10GBASE-iLR |
Connector type | LC |
Applicable cable and maximum transmission distance | Single-mode fiber: 1.4 km |
Transmit power (dBm) | -8.2 to +0.5 |
Maximum receiver sensitivity (dBm) | -14.4 |
Overload power (dBm) | 0.5 |
Extinction ratio (dB) | 3.5 |
Operating temperature | -40°C to +85°C (-40°F to +185°F) |
