Huawei Optical Transceiver OSX040N01

OSX040N01 Overview

Huawei OSX040N01 Optical Transceiver,SFP+,10G,Single-mode Module

(1550nm,40km,LC).

Brand	Huawei
Part NO	02310CNF
Product model	OSX040N01
Package type	SFP+
Transmission rate	10G
Transmission distance	40 kilometers single mode
Emission wavelength	1550nm
Receiving wavelength	1550nm
Working temperature	commercial grade 0℃～+70℃/industrial grade -40℃～+85℃ optional
Digital diagnosis	with DDM
Receiving sensitivity	single mode 40 km
Receiving sensitivity	single mode 40 km

Huawei OSX040N01 SFP+ Product Feature

• Maximum transmission rate 10.3Gbps

• 1550nm DFB laser

• Typical transmission distance 300 meters (single mode fiber)

• 3V single voltage, TTL logic interface

• Dual LC interface, support hot swap

• Support digital diagnosis function

• Comply with MSA SFP+ protocol SFF-8431 specification

• Compliant with IEEE 802.3ae 10GBASE-ER standard

• Comply with 802.3ae 10GBASE-EW standard

• Comply with SFF-8472 standard

• Working environment temperature: 0℃ to +70℃

• Applying to various areas 10 Gigabit Ethernet 10GBASE-ER 10

Gigabit Ethernet 10GBASE-EW 10 Gigabit Ethernet 1000 Base-LX

Fibre Channel 8XFC at 8.5Gbps Fibre Channel 4XFC at 4.25Gpbs

Fibre Channel 2XFC at 2.125Gpbs Fibre Channel 1xFC

at 1.0625Gbps Other fiber optic networks
