ES0W2PSA0150 Overview
Huawei ES0W2PSA0150 power module only in the S5700-28P-LI,
S5710-EI, S5720 series Switch, the switch chassis matching a
150 W AC power module.
ES0W2PSA0150 Specification
ES0W2PSA0150 Specifications | |
Part Number | 02310JFA |
Description | 150W AC Power Module(Black) |
Rated input voltage range | 100 V AC to 240 V AC, 50/60 Hz |
Maximum input voltage range | 90 V AC to 264 V AC, 47 Hz to 63 Hz |
Maximum Input current | 3 A |
Maximum output current | 12.5 A |
Rated output voltage | 12V |
Maximum output power | 150 W |
Attributes | Hardware |
Category | Outsourcing |
Product Line | Networking |
Product Family | Switch |
Product Category | Power Module |
Sub Product Family | Campus Switch |
Product Series | S5700 |
EAN | 6920702724742 |
UOM | PCS |
Pack Weight(kg) | 1.2 |
Pack Volume(m^3) | 0.005466 |
Pack Dimension (D*W*H mm) | 295*218*85 |
Net Dimension (D*W*H mm) | 270*210*80 |
