SM-X-6X1G Overview
Cisco® Gigabit Ethernet WAN Module SM-X-6X1G brings high-density
Small Form-Factor Pluggable (SFP) and copper (RJ-45) 1 Gigabit and 10
Gigabit Ethernet (GE) connectivity to the Cisco 4000 Series Integrated
Services Routers (ISRs). Providing maximum flexibility, the modules
accelerate applications such as Ethernet WAN access, inter-VLAN
routing, and high-speed connectivity to LAN switches and servers.
SM-X-6X1G Specifications | |
Product Number | SM-X-6X1G |
Product Description | 6-port Gigabit Ethernet, dual-mode GE/SFP, SM-X Module |
Form Factor | Single-wide Enhanced Service Module (SM-X) |
Cisco 4000 Series ISR support | Platforms with SM-X slot |
Auto-switchover and auto-failover | Yes |
Input packet classification on module | Yes |
MACsec support (IEEE 802.1AE) | No |
Dimensions (H x W x D) | 1.57 x 8.11 x 8.15 in (40 x 206 x 207 mm) |
Weight | 872 grams |
Operating temperature | 32 to 104°F (0 to 40°C) |
Storage temperature | -38 to 150°F (-40 to 70°C) |
Relative humidity | 5 to 95% |
Operating humidity | 5 to 85% |
