SM-X-4X1G-1X10G Overview
Cisco® Gigabit Ethernet WAN Module NIM-2GE-CU-SFP brings high-density
Small Form-Factor Pluggable (SFP) and copper (RJ-45) 1 Gigabit and 10
Gigabit Ethernet (GE) connectivity to the Cisco 4000 Series Integrated
Services Routers (ISRs). Providing maximum flexibility, the modules accelerate
applications such as Ethernet WAN access, inter-VLAN routing, and
high-speed connectivity to LAN switches and servers.
SM-X-4X1G-1X10G Specifications | |
Product Number | SM-X-4X1G-1X10G |
Product Description | 4-port Gigabit Ethernet, dual-mode GE/SFP or 1-port 10G SFP+, SM-X Module |
Form Factor | SM-X |
Cisco 4000 Series ISR support | Platforms with SM-X slot |
Auto-switchover and auto-failover | Yes |
Input packet classification on module | Yes |
MACsec support (IEEE 802.1AE) | No |
Dimensions (H x W x D) | 1.25 x 3.50 x 7.24 in. (32 x 89 x 184 mm) |
Weight | 848 grams |
Operating temperature | 32 to 104°F (0 to 40°C) |
Storage temperature | -38 to 150°F (-40 to 70°C) |
Relative humidity | 5 to 95% |
Operating humidity | 5 to 85% |
