Cisco 2-Port Serial WAN Interface card NIM-2T

NIM-2T Overview

The Cisco Gigabit Ethernet High-Speed WAN Interface Card (HWIC) brings

Gigabit Ethernet connectivity to Cisco Integrated Services Routers routers

to accelerate applications such as Metro Ethernet access, inter-VLAN

routing, and high-speed connectivity to LAN switches.The single-port

Cisco Gigabit Ethernet HWIC provides Gigabit Ethernet optical and

copper connectivity in a compact form factor for all Cisco Integrated

Service Routers (ISRs).

NIM-2T Specification
General
Device Type	Serial adapter
Form Factor	Plug-in module
Networking
Ports	RS-232/449/530/V.35/X.21 x 2
Connectivity Technology	Wired
Data Link Protocol	RS-232, RS-530, X.21, V.35, RS-449, RS-530A
Data Transfer Rate	8 Mbps
Expansion / Connectivity
Interfaces	2 x RS-232/449/530/V.35/X.21
Miscellaneous
Compliant Standards	CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, JATE, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15 A, CAN/CSA C22.2 No. 60950-1, VCCI Class A, EN 300386, CNS 13438
Dimensions & Weight
Width	3.5 in
Depth	7.2 in
Height	1.3 in
Environmental Parameters
Min Operating Temperature	32 °F
Max Operating Temperature	104 °F
Humidity Range Operating	10 - 90% (non-condensing)
